48v 500ah lifepo4 home solar energy storage bank 25kwh lithium battery pack

Basic DescriptionsThis 25kwh home battery system built in BMS with LCD display. Besides all basic protections, this Battery system built in a LCD shows the details of this battery pack including information:Rated 48v 500Ah 25 kwh energyDisplay cells voltage and system voltageTemperature of cells and MOS/BMS Charging/Discharging current DisplayCapacity and State of Charge Display(SOC)CMX as a leading server rack and Powerwall Home Battery Manufacturer in China. We focus on LiFePo4 battery, known as LFP battery, which is the longest lifecycles and safest chemistry of all kinds of lithium battery. Our home Battery Backup reach 8000 cycles at 100%DOD. Coremax offer very good price with top quality, our powerwall home battery is 10years warranty. our battery compatible with nearly all kinds of Inverters, SMA, Solar edge, Sunny island, Deye,Growatt, Goodwe, Outback etc. look for distributorse Compatible Inverters from Customer installation site Detail Specifications:ItemUnitModule SpecificationRemarkNominal CapacityAh500Ah Discharge at 0.5CActual CapacityAh500Ahless then 250AConfiguration-5pcs 16S1P modulars . 5pcs 5kwh modulars connected in parallel. In parallelOperating Temp.Min.℃0 (Charge).-20 (Discharge)@ Temp SensorMax.℃55Storage Temp.Min.℃-20   Max.℃55 Nominal VoltageV51.2Cell 3.2VMax. VoltageV58.4Cell 3.65VMin. VoltageV40Cell 2.5VNominal Energy ContentkWh≥ 25kWh  25 kw solar system WeightKg≤300kg Resistance Consistency (10s, 25℃, 30%SOC, BOL)--15%/ 10% DC-IR Discharge Operation max current (10s, 25℃, SOC50%, BOL)A500amps (by busbar in parallel installation)120 Per 1 moduleCharge Operation max current (10s, 25℃, SOC 50% BOL)A250A(0.5C )90Per 1 moduleContinuous Discharge Operation current (25℃, SOC50%, BOL)A250A(0.5C discharge)105 Per 1 moduleContinuous Charge Operation current (25℃, SOC 50% BOL)A200Amps52.5 Per 1 moduleStandard Charge (@ 25℃ )-Constant Current: ≤0.5C Constant Voltage:3.65V End Condition(Cut off):≥0.02C for cellsThe state of charge(SOC) of the module-SOC 30%±3�fore shippingSelf Discharge Rate(SOC 100%, 25℃ , Loss/Month， @BOL)%Max 3 Safety and Reliability-Compliance with QC/T 743 test standardGBT Certificate @cellInsulationMΩMin 20MΩ/1000VDC, 25℃±5℃, RH50% Cooling type-Natural(Passive) Convection(Air Cooling)Computer Monitor Software Other Features25 kw solar system Lithium-ion based residential energy storage has been around for a couple of years. There are also open concepts that work with most solar battery technologies and any existing grid connect inverter, such as sma solar battery Storage System or any other brand existing retrofit solar system.-Safety25 kw solar system are a practical and economical battery system based on Lithium-iron-phosphate technology (LFP or LiFePO4).-scalableAvailable in standard 5kWh modules, the LFP battery modules can be easily scaled in multiples up to 200kWh in a single installation, making them suitable for a range of applications.-EfficientCoremax 25 kw solar system feature a round-trip efficiency of 92%, low self discharge rate of 3 years, and unlike traditional lead acid battery.This 48v 500ah solar battery bank is scalable energy storage based on 5pcs 48v 100ah CMX48100S. The system include LiFePO4 solar 48v 500Ah 25KWH System and the server rack cabinet.Flexible useThis 48 Volt 25 kwh battery pack design for Solar Power Systems Battery Storage. 48v 500Ah is built-in high quality BMS battery management system, which can manage and monitor cells information ,including voltage, current and temperature etc. Also, our BMS can balance cells charging and discharging to extend cycle life. Multiple batteries can connected in parallel to expand capacity and power in parallel for larger capacity and longer power.HighlightsLong lifetimes - 8000 cycles @80% DOD (dependant on actual DOD, usage & temp.) and low self-discharge rateEasily scalable and stackable 5kWh modules A self-designed BMS protects the cell from overcharge, over-discharge, over current, short circuit .Built-in accessible 125A DC breaker On/Off switch - increases safety .Communication Protocol: RS232/RS485/CanbusSimple rack-based installation systemLCD display available Final assemble on the rack mount Storage packs.  25 kw solar system for small mini solar farm in Los Angeles 25kw solar energy storage system for offgrid farm in NZ.ShippingShipping heavy Lithium battery storage system is a challenge oversea. Thanks to professional packing and shipping company cooperated with Coremax. All batteries and accessories well packed with thick foam and in wooden case. The best way to protect it from damage during shipping.
