Technical Specifications System TypeLow-voltage Energy Storage Capacity10 kWh Nominal Voltage51.2 V Maximum Current150 A @ 30 s Maximum Power7,680 W @ 30 s Rated Current100 A Depth of Discharge (DoD)95% CommunicationPylontech protocol by default via CAN / RS485 Compatible InvertersDEYE, Sofar, Growatt, Victron, Foxess, Solis, SMA, LUXPOWER, Sermatec, Renac, TBB POWER, GoodWe, IMEON, etc. Parallel Connection CapabilityUp to 16 units Cycle Life (0.5C / 0.5C)8,000 cycles @ 25°C, 70% DoD Discharge Operating Temperature Range-10°C to 55°C Charge Operating Temperature Range 5°C to 55°C Installation LocationIndoor Mounting MethodWall-mounted or floor-standing Warranty10 years Weight85 kg Dimensions (W × D × H)15 × 44 × 78 cm
