Description KEY FEATURES TURN THE TABLES The Pioneer PLX-1000 achieves stable rotation and exceptional control with its high-torque direct drive. It reaches 33⅓ rpm in only 0.3 seconds, thanks to a starting torque of 4.5 kg-cm or more. EXCELLENT SOUND DESIGN The PLX-1000 heavy-mass, die-cast zinc chassis prevents resonance and vibrations. The lower part is reinforced with 8 mm-thick resin plus 9 mm vibration-damping material at the base. A rubber-insulated tonearm reduces howling, while rubber and springs in the insulators absorb external vibrations. PICK UP THE PACE Multi-tempo control lets you speed up or slow down by ±8%, ±16% and ±50%, and a reset button instantly returns to ±0%. FLEXIBLE CONNECTIVITY Interchangeable power and audio cables connect easily, and pro-grade gold-plated RCA jacks ensure low impedance and excellent sound quality. MAIN SPECIFICATIONS Power Requirements: AC 110–120 V / 220–240 V, 50/60 Hz Power Consumption: 9 W Output: RCA × 1 Main Unit Weight: 28.88 lb Maximum Dimensions: 17.83″ (W) × 6.25″ (H) × 13.89″ (D) TURNTABLE Drive Method: Quartz-lock servo direct drive Wow and Flutter: ≤ 0.1% WRMS (JIS WTD) Motor: 3-phase brushless DC motor S/N Ratio: 70 dB (DIN-B) Braking System: Electronic brake Turntable: Aluminium die-cast, diameter 13.07″ Rotation Speed: 33⅓ rpm, 45 rpm Starting Torque: ≥ 4.5 kg-cm Rotation Speed Adjustment Range: ±8%, ±16%, ±50% Start Time: 0.3 seconds (at 33⅓ rpm) TONE ARM Arm Type: Universal S-shaped tonearm, gimbal-supported bearing, static-balance Tracking Error: Within 3° Effective Length: 9.05″ Arm Height Adjustment Range: 0.23″ Overhang: 0.59″ Stylus Pressure Variable Range: 0 oz to 0.14 oz (scale step 0.03 oz) Proper Cartridge Weight: Single cartridge 0.12–0.45 oz (with shell weight: 0.12–0.22 oz); with balanced weight only: 0.21–0.35 oz (with sub-weight: 0.33–0.45 oz)
